Mini Pagoda

Category:
  1. General Details

    The Mini Pagoda Tent features structures with widths of 2x2m, 2.5×2.5m, and 3x3m, the eave height is 2.6m. The tent frameworks (upright support and roof beams) are manufactured with 55x55x2mm four-channel high strength extruded and anodized Aluminum (6061/T6), and the PVC covers use double PVC-coated polyester textile which is flame retardant in accordance to industry standards. Our tent covers feature a professional tensioning system and can be customized with your logo. The structure is different from the traditional European tent because of its simple interior structure.

    The Mini Pagoda Tent features several improvements to provide more value to your purchase that include: bar-tensioning system instead of the rubber-tensioning system and fixed sidewall to the eave beam instead of being hung on the round bar with rings. These improvements allow our products to have increased wind loading and tightness with parts that are interchangeable.

    The Mini Pagoda Tent offers quick and easy installation and dismantles without the need for heavy equipment. This structure can be used for temporary or permanent buildings and is widely used for product production, rescue missions, exhibitions and theme park facilities. We also offer customized design service to ensure you get a product that fits your exact needs.

    The Mini Pagoda Tent is compatible with a full-range of accessories to increase functionality, such as clear PVC window sidewalls, ground anchors, weight plates, lining and curtains, glass walls, ABS walls, sandwich walls, glass doors, sliding doors, rolling doors, transparent roof covers and sidewalls, flooring systems and rain gutter systems.

    For more information please contact us!

  2. Product Specification
    Span WhidthEave HeightRidge HeightMain Profile
    2m2.3m
    3.65m55x55x2mm (4 - channel)
    2.5m2.3m
    3.93m55x55x2mm (4 - channel)
    3m2.3m
    4.12m55x55x2mm (4 - channel)
  3. 3D Drawing

    Pagada Tent

  4. Technical Data
