Eyelid Military Hangar Tent

After the new designs of the flexible gate and push-pull military hangar tent, Liri Tent has developed the polygonal eyelid military hangar tent.

Category:
  1. General Details

    After the new designs of the flexible gate and push-pull military hangar tent, in 2015 Liri Tent has developed the polygonal clamshell hangar tent. This structure adopts aluminum frame, which is sturdy and durable to resist wind loading 120km/h (0.7kn/m²) and snow loading 25-75 kg/m². Especially we add the driving system to control the movement of the frame unit and the closure and open of the PVC fabric so that we can achieve the auto operation of the door like the eyelid.

    Compared with the permanent military hangar structures, eyelid military clamshell hangar tent is very easy to dismantle and install, and all components can be shipped by plane after dismantle. When parking the plane, the installation can be completed by the crew only. Also due to the good adaptability to different terrain, the military hangar tent can be set up on both concrete ground and grassland, even for temporary grounds, which reduce the difficulty of construction on site and shorten the installation time. This military hangar tent is very suitable to use as a temporary or permanent garage for air forces and the civil aviation aircraft.

    The size of military clamshell hangar tent is not fixed, so we can customize tent size by dimensions of airplanes and demands of buyers and choose different accessories for various applications. This innovative outdoor hangar tent is flexible, movable, convenient, and cost-effective.

    This product has received national patents, patent number: 201620180982.1

  2. Product Specification
    Span WhidthEave HeightRidge HeightBay DistanceMain Profile
    20m4m6m5m204x120x4mm (4 - channel)
  3. 3D Drawing

    Eyelid Hangar Tent
