Sports Event Tent for China Open Tennis

Outdoor Tent For Tennis Sports Event

About The Project

China Open was founded in 2004. Have you watched the games on site and enjoyed the passionate battle of China Open?

In recent years, Liri supplied sport event tents for many large domestic activities. For 2019 China Open, following the 2017 China Open, Liri becomes its marquee tent supplier once again. With rich experience in sport event tents manufacture, Liri provides marquee tents as hospitality for logistics, restaurant, security, VIP reception, and other functions. These sporting event tents have many sizes and specifications, including 40m span big tents, transparent arcum tent, cube structure tent, and 3m / 4m / 6m small tent, etc.

Except for providing sport event tents for the China Open, sports event tent for china open tennis can also be equipped with a full set of accessories, such as glass door, ABS wall, and lining. We can provide a one-stop-shop for outdoor activities sports event tents solutions. High-end two levels double-decker tent has won praise from officials and guests.

Sports Event Tent Series Specifications
Span WhidthEave HeightRidge HeightBay DistanceMain Profile
8m3.3m4.53m5m152x119x3.5mm (4 - channel)
10m3.3m4.85m5m152x119x3.5mm (4 - channel)
10m4m5.55m5m152x119x3.5mm (4 - channel)
12m3.3m5.16m5m152x119x3.5mm (4 - channel)
12.5m3.3m5.29m5m152x119x3.5mm (4 - channel)
15m3.3m5.62m5m152x119x3.5mm (4 - channel)
15m4m6.32m5m152x119x3.5mm (4 - channel)
16m3.3m5.72m5m152x119x3.5mm (4 - channel)
18m3.3m6.01m5m152x119x3.5mm (4 - channel)
Feature

Frame struts: hard pressed extruded aluminum 6061/T6(15HW).

Fabric cover: high quality double PVC-coated polyester textile; 100% waterproof; flame retardant to DIN4102 B1, M2, CFM; UV resistant, tear resistant, self-cleaning ability, etc.

Connector: strong hot-dip galvanized steel

Allowed temperature condition: -30 degree Celsius +70 degree Celsius

Wind load: max. 100km/h

Snow load: 75kg/sqm (snow can’t stay if use big degree roof pitch design)

Easy to assemble and disassemble

No pole inside, 100% available interior space.
