60m Sphere Dome Tent

There is a variety of options of 60m Half Sphere Dome Tent PVC fabric, such as normal white, translucent, transparent, and other color PVC cover.

  1. General Details

    LIRI has always adhered to development and innovation of Half Sphere Dome Tent. In order to make sure of security of 60m Half Sphere Tent in the case of area expanding, we reinforce at each intersection of tent frame. Tent frame is made of high strength steel tube shell structures, stress character is very strong, wind load is grade 10-12. Its overall durability can be used as a temporary building or semi-permanent building.

    There is a variety of options of 60m Half Sphere Dome Tent PVC fabric, such as normal white, translucent, transparent, and other color PVC cover. Its unique product design concept, modern and beautiful appearance and extremely wide using range, is very popular with event companies.
    The PVC has waterproof, fire retardant and anti-aging function, the full transparent space will undoubtedly broaden their horizons, the interior scenery can be seen. At the same time, you can also print a variety of business activities pattern and information on the tent. All these  not only improve the level of activities, but also enhance commercial efficiency.

    In addition to 60m Half Sphere Dome Tent, we also provide a variety of size from dia 3m-55m. Our flexible size can be customized according to the needs of our customers. There is no limit to the terraces construction. Without any poles inside tent, it is 100% using space. Its using function is also quite extensive, a small sphere tent can be used as hotels, camps, restaurants; large sphere tent can be used for outdoor exhibitions, parties, festivals, weddings. Now sphere tent is an individual structure, but also become high-end customers preferred.

  2. Product Specification
    DiameterCeiling HeightFloor AreaVolumeSteel frameworkMembrane
    3m2.3m
    7.1m²10.7m³214kg / 0.7x0.4x0.25m19kg / 1.0x1.0x0.1m
    4m2.38m12.6m²21.5m³220kg / 0.95x0.4x0.2m29kg / 1.0x1.0x0.1m
    5m2.9m19.6m²32.7m³338kg / 1.1x0.5x0.3m46kg / 1.0x1.0x0.2m
    6m3m28.3m²56.5m³460kg / 1.1x0.7x0.6m55kg / 1.2x1.0x0.3m
    7m3.5m38.5m²90m³526kg / 1.2x0.7x0.6m74kg / 1.2x1.0x0.4m
    8m4m50.2m²134m³530kg / 1.4x0.7x0.6m94kg / 1.3x1.0x0.4m
    9m4.5m63.6m²191m³660kg / 1.5x0.7x0.6m121kg / 1.5x1.5x0.35m
    10m5m78.5m²262m³720kg / 1.7x0.7x0.8m150kg / 1.5x1.0x0.35m
    11m5.5m95m²348m³780kg / 1.9x0.7x0.9m180kg / 1.6x1.1x0.4m
    12m6m113m²452m³1240kg / 2.0x0.7x1.0m220kg / 1.6x1.2x0.4m
    13m5.82132.7m²545m³1520kg / 1.9x0.8x1.0m220kg / 1.6x1.2x0.5m
    14m6.27m153.9m²685m³1800kg / 2.0x0.8x1.0m264kg / 1.6x1.2x0.5m
    15m
    6.72m176.6m²845m³1910kg / 2.1x0.8x1.0m220kg / 1.6x1.2x0.6m
    16m7.16m201m²1030m³2020kg / 2.2x0.8x1.0m346kg / 1.6x1.2x0.7m
    17m8.5m226.9m²1285m³2810kg / 2x(2.0x0.7x0.7)m430kg / 2x(1.3x1.0x0.5)m
    18m9m254.3m²1525m³2950kg / 3x(2.0x0.6x0.7)m480kg / 4x(1.4x0.7x0.5)m
    19m9.5m283.4m²1795m³3090kg / 3x(2.0x0.6x0.7)m530kg / 4(1.4x0.7x0.5)m
    20m10m314m²2090m³3840kg / 4x(2.3x0.7x0.5)m595kg / 4x(1.5x0.7x0.6)m
    21m10.5m346.2m²2420m³4000kg / 4x(2.4x0.7x0.5)m650kg / 4x(1.5x0.7x0.6)m
    22m
    11m379.9m²2785m³4170kg / 4x(2.5x0.7x0.6)m715kg / 4x(1.5x0.7x0.7)m
    23m11.5m415.3m²3180m³3460kg / 4x(2.6x0.7x0.5)m780kg / 4x(1.5x0.6x0.7)m
    24m12m452.2m²3615m³4510kg / 5x(2.7x0.6x0.6)m850kg / 4x(1.5x0.8x0.8)m
    25m12.5m490.6m²4090m³7000kg / 8x(3.0x0.6x0.4)m925kg / 5x(1.5x0.7x0.7)m
    30m13m706.5m²5744m³8970kg / 8x(3.2x0.6x0.6)m
    1320kg / 6x(1.3x0.6x0.7)m
    35m14m961m²8170m³10400kg / 3x(3.3x1.0x1.0)m1475kg / 6x(1.3x0.8x0.8)m
    40m15m1256m²11191m³11820kg / 8x(3.5x1.0x1.0)m1840kg / 6x(1.3x0.9x0.9)m
    45m18m1589.6m²17367m³17000kg / 6x(2.9x1.0x1.0)m2250kg / 6x(1.3x1.0x1.0)m
    50m20m1962.5m²
    23823m³28000kg / 13x(2.5x1.0x1.0)m2770kg / 8x(1.3x1.0x1.0)m
    55m22m2374.6m²21710m³38000kg / 18x(2.3x1.0x1.0)m3600kg / 8x(1.3x1.0x1.0)m
    60m25m2826.0m²43524m³48000kg / 26x(2.2x1.0x1.0)m4200kg / 8x(1.3x1.0x1.0)m
